Grain-Oriented Electrical Steel (GOES), also called Cold-Rolled Grain-Oriented (CRGO) steel, is a high-performance soft magnetic alloy optimized for unidirectional magnetic flux applications, primarily power and distribution transformers. Its key advantage delivers exceptional magnetic performance along the rolling direction.Grain-Oriented Electrical Steel (GOES, CRGO) features a highly ordered Goss texture, delivering low core loss, high magnetic induction (≥1.85 T), and high permeability along the rolling direction—ideal for transformer cores.
| Product | Nominal Gauge(mm) | Grade |
| Common type | 0.23 | MG23G110 |
| MG23G120 | ||
| 0.27 | MG27G120 | |
| MG27G130 | ||
| 0.30 | MG30G120 | |
| 0.35 | MG35G135 | |
| High induction type | 0.23 | MG23P090 |
| MG23P095 | ||
| MG23P100 | ||
| 0.27 | MG27P095 | |
| MG27P100 | ||
| MG27P110 | ||
| 0.30 | MG30P100 | |
| MG30P105 | ||
| 0.35 | MG35P115 |
*only typical grades listed,for more specifications,please contact us
